The Industrial 5G LAN Router is a high-performance communication device designed for reliable data transmission, precise positioning, and intelligent remote monitoring across a wide range of industries. Combining global 5G/5G RedCap/4G connectivity, 5G LAN, RTK centimeter-level positioning, and multiple industrial interfaces, it enables seamless integration between field devices, edge networks, and cloud platforms.
Built for demanding environments, the gateway features EMC Level 4 protection, a supercapacitor, hardware and software watchdogs, and support for VPN, TR069, MQTT, and Modbus RTU/TCP to ensure secure, stable, and continuous operation.
For utility applications, it also supports the China Electric Power 1.8GHz private wireless network, NARI TF encryption cards, and power intranet communications, making it an ideal solution for modern smart grid deployments while remaining flexible for industrial IoT, transportation, energy, and infrastructure projects.
5G LAN Network Capability
- Extend local networks across wide geographic areas.
- Enable direct device-to-device communication.
- Reduce communication latency, accelerate real-time data exchange.
- Simplify industrial network architecture.
- Improve security through private 5G networking.
Power Utility Communication Ready
- Support for China Electric Power 1.8GHz private wireless network.
- Compatible with NARI TF encryption cards.
- Support for China power intranet communication.
- Designed for secure utility data transmission.
Industrial-Grade Reliability
- EMC Level 4 industrial protection.
- Operating temperature: -30°C to 70°C.
- Built-in supercapacitor for power-loss protection.
- Hardware and software watchdogs ensure stable operation.
Centimeter-Level Positioning
- Integrated BeiDou RTK positioning.
- Provides centimeter-level location accuracy.
- Ideal for power asset tracking and patrol management.
- Improves positioning reliability in field operations.
Seamless System Integration
- Rich interfaces for easy integration with field devices and controllers.
- Support for Modbus RTU and Modbus TCP.
- Support for MQTT cloud communication.
- VPN secure networking.
- TR069 remote device management.
| Cellular | |
| Frequency Bands | 3GPP Release 17 RedCap 5G NR：N1/N3/N5/N8/N28/N41/N78/N79 LTE-TDD Band B34/B38/B39/B40/B41 LTE-FDD B1/B3/B5/B8 *more bands can be supported with different SKU |
| Interfaces | |
| Ethernet Interface | 2 x 10/100/1000 Mbps, RJ45 (auto-sensing) (1*WAN/LAN，1*LAN) |
| Serial Interface | 1*RS232+1*RS485 |
| USB | 1*Type-A，USB2.0，for expansion |
| Console Interface | 1*Type-A，USB2.0， |
| External antenna interface | 5G*2, 1*GNSS，1* backup |
| SIM Slot | 2*1.8V Mini SIM |
| TF Slot | 1 (built-in), for expansion |
| Power | |
| Power Supply | DC 9-36V |
| Consumption | 5G: ＜15W; 5G Redcap: ＜5W; 4G: ＜8W |
Typical Industries & Applications
Smart Grid & Utilities
Support smart distribution, substations, transmission lines, and utility asset monitoring with secure and reliable communications.
Renewable Energy
Enable remote monitoring of solar farms, wind farms, battery energy storage systems (BESS), and distributed energy assets.
Industrial Automation
Connect PLCs, sensors, RTUs, and industrial controllers for factory automation, process monitoring, and predictive maintenance.
Oil & Gas
Provide secure communications for pipelines, wellheads, compressor stations, storage facilities, and remote production sites.
Mining
Enable equipment monitoring, fleet management, personnel positioning, and industrial communications in demanding mining environments.
Smart Transportation
Support intelligent transportation systems (ITS), roadside equipment, traffic signal controllers, and highway monitoring.
Railway Infrastructure
Connect railway signaling equipment, power systems, stations, and trackside monitoring devices with reliable wireless communications.
Ports & Logistics
Provide real-time connectivity for container terminals, cranes, automated guided vehicles (AGVs), warehouses, and logistics hubs.
Smart Construction
Monitor construction equipment, temporary job sites, mobile assets, and field operations with reliable wireless connectivity.
Agriculture
Support precision agriculture, irrigation control, weather stations, autonomous machinery, and farm equipment management.
Water & Wastewater
Enable remote monitoring of pumping stations, reservoirs, water treatment plants, drainage systems, and pipeline networks.
Environmental Monitoring
Collect and transmit environmental data from weather stations, air quality sensors, flood monitoring systems, and disaster warning networks.
Smart Cities
Support intelligent street lighting, public infrastructure, utility management, environmental sensing, and city-wide IoT deployments.
Telecommunications
Provide reliable backhaul connectivity for communication cabinets, remote base stations, edge sites, and distributed telecom infrastructure.
Fleet & Mobile Asset Management
Deliver real-time positioning, vehicle communications, and remote diagnostics for service vehicles, engineering fleets, and mobile equipment.
Critical Infrastructure
Ensure secure and reliable communications for airports, seaports, energy facilities, public safety systems, and other mission-critical infrastructure.
